Serial number |
Name |
Numerical value |
Unit |
|
1. |
Maximum thickness that can be cut Ordinary board |
12 |
mm |
|
Stainless steel material |
10 |
mm |
|
2. |
Maximum board width that can be cut |
2500 |
mm |
|
3. |
Strength of sheared sheet metal |
450-650 |
N/mm2 |
|
4. |
Shear angle |
0.5-2 º |
|
|
5. |
Maximum distance of rear blocking material |
800 |
mm |
|
6. |
Number of trips |
8-35 |
min-1 |
|
7. |
Distance between columns |
2730 |
mm |
|
8. |
Main parameters of the machine:
Blade length |
2600 |
mm |
|
9. |
The height of the workbench above the ground |
840 |
mm |
|
10. |
Main motor Model |
Y160L-4/B5 |
|
|
Power |
15 |
KW |
|
Speed |
1460 |
r/min |
|
11. |
Rear blocking material |
|
|
|
Motor Model |
Model YS7114 |
variable frequency speed control |
|
Power |
0.37 |
KW |
|
Speed |
1500 |
r/min |
|
12. |
Gear pump Model |
NB4-G40F |
|
|
Traffic |
40 |
L/min |
|
Pressure |
31.5 |
Mpa |
|
13. |
Overall dimensions |
Long 3150 |
mm |
|
Wide 1660 |
mm |
|
Tall 2200 |
mm |
|
14. |
Machine weight |
8.5 |
T |
